Flexible Permanent Sm2Co17 Magnet High Heat Resistant Magnets Epoxy Coated

Product Categories
Mianyang Henshin Magnetic Material Co., Ltd.
Contact Now

Flexible Permanent Sm2Co17 Magnet High Heat Resistant Magnets Epoxy Coated

  • 1
  • 2
  • 3

Brand Name : HSMAG

Model Number : Sm2Co17

Certification : ITAF16949 ISO9001

Place of Origin : China

MOQ : 1PCS

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 100000PCS 15Days

Delivery Time : 15 work days

Packaging Details : Cartons, sheet metal shielding packaging

Size : Customized

Material : Sintered SmCo Magnet

Grade : XG16-XG33EH

Max Working Temperature : 350℃

Tolerance : 0.05mm, 0.05mm ~ 0.1mm

Lead Time : 15 work day

Sample : Free

Coating : etc, Ni, Zn, Epoxy.Black Epoxy. Nickel.Silver.etc,

Contact Now

Permanent Samarium Cobalt High Temperature Magnet,flexible magent, permanent magent
Products Description

SmCo5 magnet is composed of SmCo alloy with Sm Co ratio of 1:5. According to weight, Sm accounts for 36% of the total. This SmCo alloy usually contains 36% Sm and a small amount of Co. This series of SmCo magnets can provide a maximum magnetic energy product of 25 MGOe and a reversible temperature coefficient of - 0.05% / ℃. In addition, this series is easier to calibrate to a specific magnetic field than Sm2Co17 series. The Sm2Co17 magnet consists of SmCo alloy with a SmCo ratio of 2:17. It also contains other elements, such as iron, copper, zirconium and hafnium in a small amount. The magnetic energy product of this property is higher, up to 32 MGOe, and the reversible temperature coefficient is - 0.03% / ℃.

The specific proportion is Sm: 23-28%; Rare earth metal Cobalt: 48-52%; Metallic element Fe: 14-17%; Metal element Cu: 5-7%; A small amount of Zr: 2-3% was added.

Sm 23-28%
Co 48-52%
Fe 14-17%
Cu 5-7%
Zr 2-3%

Flexible Permanent Sm2Co17 Magnet High Heat Resistant Magnets Epoxy CoatedFlexible Permanent Sm2Co17 Magnet High Heat Resistant Magnets Epoxy Coated

Froperties of SmC0 Magnets


Flexible Permanent Sm2Co17 Magnet High Heat Resistant Magnets Epoxy Coated

Company Profile

Mianyang Hengxin Magnetic Materials Co., Ltd. was founded in 1999, specializing in the manufacture and development of sintered samarium cobalt permanent magnet materials and devices; after years of development, it has formed a production capacity of 500 tons of samarium cobalt permanent magnet materials per year, and is the main manufacturer of samarium cobalt permanent magnet materials and devices in China.
